Technical Specifications |
||||
|
M80 BALL |
M62 TRACER |
M61 AP |
||
|
Bullet Weight |
149 gr (~ 9.67 g) |
146 gr (~ 9.46 g) |
150 gr (~ 9.75 g) |
|
|
Bullet Material |
Jacket- Tombac/CuZn10 Core – Lead Antimony |
Jacket – Tombac plated steel strip or copper washer steel strip Core - Lead Antimony Tracer - Tracer Comp. |
Jacket – Tombac plated steel strip or copper washer steel strip Core – Steel |
|
|
Bullet Lenght |
26,46 mm |
34,29 mm |
32,2 mm |
|
|
Case Material |
Brass CuZn30 |
|||
|
Case Lenght |
51,18 mm |
|||
|
Primer Type |
Boxer, non corrosive |
|||
|
Powder Type |
Double Base Powder |
|||
|
Chamber Pressure |
Max. 3800 bar |
|||
|
Port Pressure |
Min. 550 Bar |
|||
|
Velocity (m/s) at 16 m |
833 ± 10m/s |
817 ± 10m/s |
838 ± 10m/s |
|
|
Accuracy (Standart Deviation) |
Max. 200 mm at 550 m |
Max. 300 at 550 m |
Max. 200mm at 550 m |
|
|
Action Time |
˂ 4 ms |
|||
|
Extraction Force |
Min. 27 kgf/265N |
|||
|
Cartridge Lenght |
71,12 mm |
|||
|
Waterproofness |
Applied |
|||
|
Temperature Range |
-54 °C to +52°C |
|||
|
Referance Document |
NATO STANAG 2310/NATO STANDARD AEP-97 |
|||
Penetration (M61): The bullet of the sample cartridges demonstrate complete penetration of 3,5mm thickness SAE 1010 or SAE 1020 mild steel plate target with a Rockwell hardness of min. B55 and max. B70 that plated 550m from the weapon.
PACKING 1
20 rounds in cardboard box
10 cardboard boxes (200 rounds) in PVC bag
10 PVC (2.000 rounds) bags in wooden case
PACKING 2
250 rounds in metal link belt M13
2 metal link belts in metal box M2A1 (500 rounds)
2 metal boxes M2A1 (1.000 rounds) in wire bound wooden box
