Technical Specifications |
||
|
(M855/SS109) BALL |
(M856 /L110) TRACER |
|
|
Bullet Weight |
62 gr (~ 4.0 g) |
61 gr (~ 3.92 g) |
|
Bullet Metarial |
Jacket – Tombac/CuZn10 Core 1 - Lead Antimony Core 2 - Steel |
Jacket – Tombac plated steel Strip or copper washer steel strip Strip Core – Lead Antimony Tracer – Tracer Composition |
|
Bullet Lenght |
23,4 mm |
28,45 mm |
|
Case Metarial |
Brass CuZn30 |
|
|
Case Lenght |
44.7 mm |
|
|
Primer Type |
Boxer non corrosive |
|
|
Powder Type |
Double Base Powder |
|
|
Chamber Pressure |
Pmax + 3Sd ˂ 4450 Bar |
|
|
Port Pressure |
Port – 3Sd > 1030 Bar |
|
|
Velocity (m/s) at 24 m |
920 ± 20m/s |
900± 20m/s |
|
Accuracy (Standart Deviation) |
Max. 20 cm at 550 m |
Max. 30 cm at 550 m |
|
Action Time |
˂ 3 ms |
|
|
Extraction Force |
Min. 20,4 kgf/200N |
|
|
Catridge Lenght |
57,4 mm |
|
|
Waterproofness |
Applied |
|
|
Temperature Range |
-54 °C to +52°C |
|
|
Referance Document |
NATO STANAG 4172/NATO STANDARD AEP-97 |
|
Penetration (M855/SS109): The bullet of the sample cartridges demonstrate complete penetration of 3.5mm thickness SAE 1010 or SAE 1020 mild steel plate target with a Rockwell hardness of min. B55 and max. B70 that plated 570m from the weapon.
PACKING 1
30 rounds in cardboard box
15 cardboard boxes (450 rounds) in PVC bag
5 PVC bags (2.250 rounds) in wooden case
PACKING 2
200 rounds in metal link belt M27
4 metal link belts in metal box M2A1 (800 rounds)
2 metal boxes M2A1 (1.600 rounds) in wire bound wooden box
