TECHNICAL SPECIFICATIONS |
||
|
Bullet Type |
M33 BALL |
M17 TRACER BALL |
|
Bullet Weight |
653 gr (~42,3 g) |
618 gr (~40,0 g) |
|
Bullet Material |
Jacket – Tombac Core – Steel Cup Closure- Lead Antimony Filler Point- Borax |
Jacket – Tombac plated steelstrip or copper washer steel strip Core- Lead Antimony Tracer- Tracer Comp. |
|
Case Material |
Brass CuZn30 |
|
|
Case Length |
~99,31 mm |
|
|
Primer Type |
12.7 mm Primer, Boxer, non-corrosive |
|
|
Powder Type |
Spherical, Double Base Powder |
|
|
Case Mouth Pressure |
Pmax + 3Sd ˂ 4500 Bar |
|
|
Port Pressure |
||
|
Velocity (m/s) at 24 m |
887 ± 12 m/s |
887 ± 12 m/s |
|
Accuracy (Standard Deviation) |
Max. 300 mm at 550 m |
Max. 400 mm at 550 m |
|
Trace |
Visible trace of full luminosity from a point not greater than 200m from the muzzle of the weapon to a point not less than 1500 m from the muzzle |
|
|
Action Time |
˂ 4.5 ms |
|
|
Extraction Force |
Min. 91.7 kgf / 900 N |
|
|
Cartridge Length |
~138,4 mm |
|
|
Waterproofness |
Applied |
|
|
Temperature Range |
-54 °C to +52°C |
|
|
Reference Document |
AEP-97 MULTI-CALIBRE MANUAL OF PROOF AND INSPECTION (M-CMOPI) FOR SMALL ARMS AMMUNITION Aop-4383 Technical Performance Specification Providing For The Interchangeability Of 12,7 mm x 99 Ammunition And Links |
|
